Photo: selective rack starter bay
Designed to RMI and ANSI MH16.1 load standards, with capacities engineered for your pallet weights and seismic zone. We handle load calculations, drawings, and code details with you.
| Capacity per level | 5,400 lb (uniformly distributed) |
|---|---|
| Bay width | 96 in (8 ft) between uprights |
| Frame depth | 42 in |
| Frame height | 144 in (12 ft) |
| Levels | 3 (2 beam levels + floor) |
| Beam type | 1-5/8 in step beam, roll-formed |
| Upright gauge | 18 ga, 3 in × 3 in column |
| Finish | Powder-coat, teal upright / orange beam (standard) |
| Connection | Tear-drop, boltless with safety clips |
| Compliance | RMI / ANSI MH16.1, seismic configurable |
| Approx. ship weight | 412 lb / bay |
| Lead time | 3–5 business days (in stock) |
Selective pallet racking gives you direct access to every pallet, which makes it the most flexible and widely used layout for operations with many SKUs and steady turnover. It is the lowest cost per position to install and the easiest to reconfigure as inventory changes.
This starter bay is a complete, free-standing unit, two upright frames and three storage levels. Add adder bays to extend a row, sharing one upright frame between each bay to lower your cost per position.
Send us your pallet sizes, weights, ceiling height, and forklift type. A specialist will return a rack layout with capacities, a drawing, and lead times. We can add wire decking, pallet supports, row spacers, column protectors, and guardrails to protect the system and your people.
2 × upright frames (3" × 3", 18 ga, 144" H × 42" D) · 6 × step beams (96") · 12 × safety clips · baseplates & anchors · load capacity placard.
Wire decking (3 per bay) · pallet supports · row spacers · column protectors · end-of-row guards. Add these to your quote and we’ll confirm the complete configuration and freight.
Tell us your pallet sizes, weights, ceiling height, and forklift type. A specialist returns a layout with capacities, a drawing, and lead times, usually within one business day.
